The TXA082 M.2 Gigabit Ethernet Adapter is a high performance 10/100/100 BASE-T Ethernet LAN Controller

It is suitable for converting the M.2 slot at the PC end into Gigabit Ethernet RJ45 Interface

Supporting Features such as NDIS5 checksum and large send offload for lower CPU Utilization

Jumbo frames and VLAN Tagging, this M.2 Gigabit Adapter is ready to handle a wide variety of scenarios

Applications:

Add a Gigabit networking port to a PC with a M.2 slot

Replacement for a failed built-in Gigabit Ethernet Port

Features:

M.2 2242 Key B/M

A single 10/100/1000Mbps compatible RJ45 Ethernet Port

2 status LEDs for link and activity

Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x and IEEE 802.3ab standards

Supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control

9KB Jumbo Frame Support

Microsoft NDIS5 Checksum Offload (IPV4, TCP, UDP) and Large Send Offload Support

Full and half Duplex Support

Crossover Detection & Auto-Correction (Auto MDI/MDI-X)

Specifications:

Form Factor	M.2 2242 B-M
Card Type	Embedded
Chipset ID	Realtek RTL8111H
Industry Standards	IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab,1000BASE-T
	IEEE 802.3az Energy-Efficient Ethernet, IEEE 802.3x Flow
	Control, 802.1q VLAN Tagging, 802.1p Layer 2 Priority Encoding
Interface RJ45	(Gigabit Ethernet)
Max Power Consumption	0.6W (3.3V@170mA)
Ports	1
Performance Auto
MDIX	Yes
Auto-Negotiation	Yes
Compatible Networks	10/100/1000 Mbps
Flow Control	Full duplex flow control
Full Duplex Support	Yes
Jumbo Frame Support	9K max.
Maximum Data Transfer Rate	2 Gbps (Ethernet; Full-Duplex)
Connector(s)
Connector Type(s)	1 M.2 B+M Key
External Ports	1 – RJ-45 Female
Software
OS Compatibility	Windows 7, 8.x, 10, 11
	Windows Server 2008 R2, 2012, 2016, 2019, 2022; Linux 2.6.31 to 5.x
